P/N: CHX150-08CE-G Key Specs
Item
CHEMICAL HOSE ASSEMBLY 1-1/2 ID X 8 FT.
OEM
Continental
OEM #
CHX150-08CE-G
Condition
New OEM Original
Returnable
No
Bend Radius
4 in
Burst Pressure
800 psi
Compatible Chemicals
Acetic Acid (Glacial), Acetic Acid 20%, Acetic Acid 80%, Chromic Acid 5%, Chromic Acid 10%, Chromic Acid 30%, Chromic Acid 50%, Citric Acid 50%, Formic Acid, Hydrochloric/Muriatic Acid (20%), Hydrochloric/Muriatic Acid (37%), Hydrochloric/Muriatic Acid (100%), Hydrofluoric Acid (
Hose Color
Black
Hose Configuration
Coupled Assembly
Hose Cover Material
EPDM
Hose Fitting A Material
316 Stainless Steel
Hose Fitting A Size
1-1/2 in
Hose Fitting A Type
Cam and Groove E
Hose Fitting B Material
316 Stainless Steel
Hose Fitting B Size
1-1/2 in
Hose Fitting B Type
Cam and Groove C
Hose Inside Dia.
1-1/2 in
Hose Length
8 ft.
Hose Outside Dia.
1-15/16 in
Hose Reinforcement Material
Carbon Steel
Hose Reinforcement Type
Helix
Hose Tube Material
Cross-Linked Polyethylene
Max. Working Pressure @ 70 F
200 psi
Mfr. Model #
CHX150-08CE-G
Not Recommended Chemicals
Xylene, Methyl Chloride, Anhydrous Ammonia, Ammonia (Liquids), Turpentine
Safety Factor
4:1
Shipping Weight
8.3 lbs.
Static Control Wire
Yes
Temp. Range
-40 Degrees to 250 Degrees F
