P/N: 8501KFR12V20 Key Specs
Item
H8096 FLANGE RELAY 120VAC 8 PINS 12A @ 240V AC
OEM
Square D
OEM #
8501KFR12V20
Condition
New OEM Original
Returnable
No
AC Contact Rating — Relay
12A @ 240V
Body Depth — Relay
1.4 in
Body Height — Relay
1.9 in
Body Width — Relay
1.4 in
Coil Volts
120V AC
Contact Form — Relay
DPDT
Contact Material
Silver Cadmium Oxide
DC Contact Rating — Relay
12A @ 28V
Electrical Connection
0.187 in Push On Terminal
HP @ 120V
1/3 hp
HP @ 240V
1/2 hp
Item — Relay
Flange Mount Relay
Mounting — Relay
Side Flange
Number of Pins — Relay
8
Overall Height — Relay
2.75 in
Power Consumption — Relay
2.5 VA
Standards
CE Marked, CSA Certified, UL Listed
Status Indicator
No
