P/N: 8215A040CSA Key Specs
Item
SOLENOID VALVE 2-WAY/2-POSITION NC AIR
OEM
Red-Hat
OEM #
8215A040CSA
Condition
New OEM Original
Returnable
No
Ambient Temperature Range
32 Degrees to 125 Degrees F
Application
Air and Vacuum Service
Body Material — Valves
Aluminum
BtuH
7,430,000 BtuH
Center Line Pipe Center Size
7-29/32 in
Coefficient of Volume
138
Coil Enclosure
General Purpose No Junction Box
Coil Insulation Class
F
Electrical Connections
1/2 in Conduit w/18 in Leads
Environmental Rating — Valves
Indoor, Outdoor
Hz
50/60
Max Fluid Temperature
125 Degrees F
Max Operating Pressure Differential
5 psi
Max Operating Pressure Differential Air/Inert Gas
5 psi
Max Operating Pressure Differential Water
5 psi
Media — Valves
Air, Fuel Gas
Min Operating Pressure Differential
0 psi
NEMA Rating
1
Orifice Diameter
3 in
Overall Height
10-1/4 in
Overall Length
7-25/32 in
Overall Width
7-51/64 in
Pipe Size — Valves
3 in
Seal Material — Valves
NBR
Solenoid Valve Product Group
Air and Fuel Gas Solenoid Valve
Standards
CSA, UL
Valve Configuration
Normally Closed
Valve Ways and Positions
2-Way/2-Position
Voltage
120V AC
Watts
28.2 W
