P/N: 7311BMUC3 Key Specs
Item
ANGULAR CONTACT BALL BEARING, FLUSH GROUND, 55MM BORE X 120MM OD X 29MM W
OEM
Nachi America Inc
OEM #
7311BMUC3
Condition
New OEM Original
Returnable
No
Bore (Mm)
55
Bore Diameter Millimeters
55
Cage Type
Machined Brass
Contact Angle
40°
Dynamic Load Rating (N) Duplex
121,000
Dynamic Load Rating (N) Single
74,300
Max Speed (Rpm) / Oil Single
6,700
Max Speed (Rpm) Oil Duplex
5,400
Od (Mm)
120
Outer Diameter Millimeters
120
Radial Clearance
C3
Series
7200
Static Load Rating (N) Duplex
104,000
Static Load Rating (N) Single
52,000
Tolerance
ISO Class 0
Width Millimeters
29
