P/N: 6Z400 Key Specs
Item
AC GEARMOTOR 8.5 RPM TEFC 115V
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
6Z400
Condition
New OEM Original
Returnable
No
Bearings
Heavy Duty Ball, Needle Roller and Thrust Balls on Case, Ball on Motor
Full Load Amps
4
Gear Case Material
Die Cast Aluminum
Gear Material
Hardened Steel
Gear Ratio
210:1
Gear Type
Helical First Stage/Subsequent Stages Spur/AGMA Class 9
Gearmotor Brake Type
None
Gearmotor Enclosure
Totally Enclosed Fan-Cooled
Gearmotor Mounting Position
All Angle
Gearmotor Phase
1
Gearmotor Rotation
CW/CCW
Gearmotor Shaft Orientation
Parallel
Gearmotor Shaft Type
Single
Gearmotor Type
AC Gearmotor
Gearmotor Voltage
115V AC
Gears
Hardened Steel, 1st Stage Helical, Subsequent Stages Spur, AGMA Class 9
Housing
Die Cast Aluminum
Hz
60 Hz
Input HP
1/4 hp
Length Less Shaft
12 5/16 in
Lubrication
Permanent Heavy Duty Gear Oil
Max. Ambient Temp.
40 Degrees C
Max. Torque
974.0 in-lb
Motor Type
Split-Phase
Nameplate RPM
8.5 RPM
Overhung Load
325 lb
Seals
Lip Type on Input and Output Shaft
Shaft Dia. (Dimension U)
3/4
Shaft Length (Dimension V)
1.5
Standards
UL Recognized, CSA Certified
Thermal Protection
None
