P/N: 6Z081 Key Specs
Item
AC GEARMOTOR 17 RPM TENV 115V
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
6Z081
Condition
New OEM Original
Returnable
No
Bearings
Heavy Duty Needle on Case, Ball on Motor
Capacitor Required
2MDV6
Full Load Amps
0.6
Gear Case Material
Die Cast Aluminum
Gear Material
Steel or Heat Treated Powdered Metal
Gear Ratio
96:1
Gear Type
Helical First Stage/Spur
Gearmotor Brake Type
None
Gearmotor Enclosure
Totally Enclosed Nonventilated
Gearmotor Mounting Position
All Angle
Gearmotor Phase
1
Gearmotor Rotation
CW/CCW
Gearmotor Shaft Orientation
Parallel
Gearmotor Shaft Type
Single
Gearmotor Type
AC Gearmotor
Gearmotor Voltage
115V AC
Gears
1st Stage Steel, Helical, Subsequent Stages Steel or Heat Treated Powdered Metal Spur
Housing
Die Cast Aluminum
Hz
60 Hz
Input HP
1/20 hp
Length Less Shaft
7 3/8 in
Lubrication
Permanent Heavy Duty Gear Oil
Max. Ambient Temp.
40 Degrees C
Max. Torque
100.0 in-lb
Motor Type
PSC
Nameplate RPM
17 RPM
Overhung Load
90 lb
Seals
Spring Loaded Lip Type on Input and Output Shaft
Shaft Dia. (Dimension U)
1/2
Shaft Length (Dimension V)
1
Standards
UL Recognized, C-UL Recognized
Thermal Protection
None
