P/N: 6204FT150 Key Specs
Item
RADIAL BEARING DOUBLE SEAL 20MM BORE DIA
OEM
NTN
OEM #
6204FT150
Condition
New OEM Original
Returnable
No
ABEC Tolerance
1
Bearing Material
Steel
Bore Dia.
20 mm
Bore Tolerance
+0/-10 micron
Cage Material
Steel
Dynamic Load Capacity
2,900 lb
Industry Number
6204FT150
Lubrication
Hi Temp
Max. RPM
9,300 RPM
Outside Dia.
42 mm
Outside Dia. Tolerance
+0/-11 micron
Seal Material
Viton
Seal/Shield Type
Double Sealed
Shield Material
Steel
Single Row/Double Row
Single Row
Static Load Capacity
1,500 lb
Temp. Range
230 Degrees to 250 Degrees F
Unmounted Bearing Item
Radial Ball Bearing
Width
17 mm
