P/N: 5WJC5 Key Specs
Item
ROOM AIR COND MTR PSC 1/2 OAO 1075 RPM
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
5WJC5
Condition
New OEM Original
Returnable
No
Body Diameter
5-5/8 in
Bolt Circle Diameter
5-1/8 in
Capacitor Required
Included
Duty
Continuous Air Over
Frame
48Y
Full Load Amps
6.5
HP
1/2
Hz
60
Includes
10 MFD 370V AC Capacitor
Ins. Class
B
Lead Length
60 in
Length Less Shaft
5-15/16 in
Max Ambient Temperature
60 Degrees C
Motor Application
HVAC/R
Motor Bearings
Sleeve
Motor Design
Permanent Split Capacitor
Motor Enclosure Design
Open Air-Over
Motor Mounting Type
Cradle Base
Motor Service Factor
1
Motor Shaft Design
Flat
Motor Shaft Rotation
CW/CCW
Motor Sub Application
Room Air Conditioner
Motor Thermal Protection
Auto
Mounting Stud Pattern
3-5/8 in x 3-5/8 in
Nameplate RPM
1075
Number of Speeds
4
Phase
1
Resilient Ring Diameter
2-1/2 in
Ring to Ring Center
5-15/32 in
Shaft Diameter
1/2 in
Shaft Length
8-1/2 in
Standards
CSA Certified (258501), UL Recognized (E37403)
Stud Size
#8-32 UNC
Voltage
115
