P/N: 5VNG8 Key Specs
Item
D8504 ROUND REPAIR AIR CYLIN 1-1/2INBORE
OEM
Speedaire
OEM #
5VNG8
Condition
New OEM Original
Returnable
No
Air Cylinder Bore Dia.
1 1/2 in
Air Cylinder Mount
Basic
Air Cylinder Product Group
Air Cylinder
Air Cylinder Type
Round Body
Body Material
Aluminum
Bore Dia.
1 1/2 in
Cushion Type
Head and Cap
Cylinder Action
Double Acting
Cylinder Type
Round
End Cap Material
Aluminum
Finish
Silver
Magnetic Piston
Yes
Max. Pressure
150 psi
Mount
Basic
Nose Mount Thread
1-14
Overall Length
17.1875 in
Piston Material
Anodized Aluminum
Piston Rod Material
Chrome Plated Steel
Pivot Hole Dia.
0.3125 in
Port Size
1/4 in
Rod Dia.
0.5 in
Rod Thread Length
1.25 in
Rod Thread Size
1/2-13
Single Acting/Double Acting
Double Acting
Stroke
10 in
Temp. Range
-10 Degrees to 165 Degrees F
Tube Material
Anodized Aluminum
