P/N: 5VNE3 Key Specs
Item
D8497 ROUND REPAIR AIR CYLIN 1-1/8INBORE
OEM
Speedaire
OEM #
5VNE3
Condition
New OEM Original
Returnable
No
Air Cylinder Bore Dia.
1 1/8 in
Air Cylinder Mount
Basic
Air Cylinder Product Group
Air Cylinder
Air Cylinder Type
Round Body
Body Material
Aluminum
Bore Dia.
1 1/8 in
Cushion Type
Head and Cap
Cylinder Action
Double Acting
Cylinder Type
Round
End Cap Material
Aluminum
Finish
Silver
Magnetic Piston
Yes
Max. Pressure
150 psi
Mount
Basic
Nose Mount Thread
3/4-16
Overall Length
13.6875 in
Piston Material
Anodized Aluminum
Piston Rod Material
Chrome Plated Steel
Pivot Hole Dia.
0.25 in
Port Size
1/8 in
Rod Dia.
0.375 in
Rod Thread Length
0.875 in
Rod Thread Size
3/8-16
Single Acting/Double Acting
Double Acting
Stroke
8 in
Temp. Range
-10 Degrees to 165 Degrees F
Tube Material
Anodized Aluminum
