P/N: 5VMA8 Key Specs
Item
D8565 ISO AIR CYLIN 63MM BORE 125MM STROKE
OEM
Speedaire
OEM #
5VMA8
Condition
New OEM Original
Returnable
No
Air Cylinder Bore Dia.
63 mm
Air Cylinder Mount
ISO MX0
Air Cylinder Product Group
Air Cylinder
Air Cylinder Type
ISO
Body Material
Aluminum
Bore Dia.
63 mm
Cushion Type
Head and Cap
Cylinder Action
Double Acting
Cylinder Type
ISO
End Cap Material
Anodized Aluminum
Magnetic Piston
Yes
Max. Pressure
145 psi
Mount
ISO MX0
Overall Length
315 mm
Piston Material
POM
Piston Rod Material
Case Hardened, Chrome Plated Steel
Port Size
3/8 in BSPP
Rod Dia.
20 mm
Rod Thread Length
32 mm
Rod Thread Size
M16 x 1.5 in
Single Acting/Double Acting
Double Acting
Standards
AFNOR Installation and dimensional Standards., ISO 6431, ISO/DIS 15552, VDMA 24562
Stroke
125 mm
Temp. Range
-4 Degrees to 176 Degrees F
Tube Material
Anodized Aluminum
