P/N: 573CF112G-3-HV Key Specs
Item
CONE EXHAUST FAN 57 IN 208-230/460V 3 PH
OEM
JJS Technical Services
OEM #
573CF112G-3-HV
Condition
New OEM Original
Returnable
No
Bearing Type
Self-Aligning Pillow Block
CFM @ 0.000 in SP
33,500
CFM @ 0.050 in SP
31,500
CFM @ 0.100 in SP
29,600
CFM @ 0.150 in SP
27,400
CFM/Watt @ 0.000 in SP
23
CFM/Watt @ 0.050 in SP
20.8
CFM/Watt @ 0.100 in SP
18.9
CFM/Watt @ 0.150 in SP
17.1
Cone Depth (Inches)
34-3/4 in
Cone Diameter (Inches)
67 3/8 in
Fan RPM
557
Flange Width (Inches)
3 in
Frame Finish
Gel Coat
Frame Material
Fiberglass
Free Area (Square-Feet)
21
Full Load Amps
4.6-4.8/2.4
HP
1 1/2 hp
Height (Inches)
67-1/2 in
Hz
60
Max Ambient Temperature (F)
104 Degrees F
Max Depth (Inches)
62 3/4 in
Mesh Size
2-1/2 in
Motor Enclosure
Totally Enclosed Nonventilated
Motor Insulation
Class F
Motor RPM
1750
Motor Type
Energy Efficient
Mounting Location
Wall
Number of Blades
3
Opening Required H (Inches)
62-1/2 in
Opening Required W (Inches)
62-1/2 in
Phase
3
Propeller Diameter (Inches)
57 in
Propeller Material
Galvanized Steel
Shaft Diameter (Inches)
1 in
Type
Cone, Belt Drive
Venturi Clearance Diameter (Inches)
57 5/8 in
Venturi Depth (Inches)
28 in
Voltage
208-230/460
Watts
1,565 W
Width (Inches)
67-1/2 in
