P/N: 53DD29 Key Specs
Item
GENERAL PURPOSE MOTOR 3 HP 3490 RPM
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
53DD29
Condition
New OEM Original
Returnable
No
CC Number
CC030A
Duty
Continuous
Frame
143/5T
Full Load Amps
7.8-7/3.5
HP
3
Hz
60/50
Ins. Class
F
Inverter Rated
Yes
Length Less Shaft
10-1/2 in
Manufacturers Warranty Length
1 yr
Max Ambient Temperature
40 Degrees C
Motor Application
General Application
Motor Bearings
Ball
Motor Design
3-Phase
Motor Efficiency Group
NEMA Premium Efficient
Motor Enclosure Design
Open Dripproof
Motor Frame Material
Steel
Motor Mounting Position
All Angle
Motor Mounting Type
Rigid Base
Motor Service Factor
1.15
Motor Shaft Design
Keyed
Motor Shaft Rotation
CW/CCW
Motor Thermal Protection
None
Nameplate RPM
3485
Nominal Efficiency
88 %
Number of Speeds
1
Overall Length
14-1/8 in
Phase
3
Shaft Diameter
7/8 in
Shaft Length
2-1/4 in
Standards
CE, CSA, UL
Voltage
208-230/460
