P/N: 521H20ARL3000 Key Specs
Item
PROFILE BALL RAIL 3000MM L 20 W 19 H
OEM
Thomson
OEM #
521H20ARL3000
Condition
New OEM Original
Returnable
No
Agency Compliance
DIN 645-1
For Use With
500 Series Ball Carriages
Mounting Hole Center to Center
60 mm
Mounting Hole Size
M5
Mounting Hole from Shaft End
30 mm
Number of Rail Holes
49
Overall Height
19 mm
Overall Length
3,000 mm
Overall Width
20 mm
Rail Finish
Hardened Steel
Rail Material
Hardened Steel
Screw Type
Hex Head
Temp. Range
-40 Degrees — 80 Degrees C, 120 Degrees C Max
Thread Size
M5
Type
500 Series
