P/N: 49G986 Key Specs
Item
FLOOR DRILL PRESS BELT 20 1 HP 120/240V
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
49G986
Condition
New OEM Original
Returnable
No
Amps AC
16/8
Base Size
14-1/8 in x 13 in
Capacity Cast Iron
1-1/4 in
Capacity Steel
1 in
Chuck Size
1/2 in
Column Diameter
4 in
Corded/Cordless
Corded
Drill Press Product Grouping
Production Drill Presses
Drilling Capacity Wood
Not Specified
Drive Type
Belt
Hz
60
Includes
Quick Belt Tension Release, Spindle Depth Stop, Different Spindle Speed Ranges, LED, Drill Chuck and Arbor
Max Spindle To Base
44-1/2 in
Motor HP
1
Number of Speeds
12
Number of T-Slots
2
Overall Depth
32-1/2 in
Overall Height
70-1/2 in
Overall Width
22-1/2 in
Phase
1
Power Down Feed Included
No
Quill Diameter
2-1/8 in
Spindle Speed
140 to 2600 rpm
Spindle Taper
MT3
Spindle Travel
5 in
Spindle to Table
26-3/8 in
Swing
20 in
Table Slot Size
5/8 in
Table Work Surface
15 in x 13 in
Voltage
120/240
