P/N: 48ZJ99 Key Specs
Item
FARM DUTY MOTOR 3-PHASE TEFC 1-1/2 HP
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
48ZJ99
Condition
New OEM Original
Returnable
No
Duty
Continuous
Finish
Epoxy
Frame
56
Full Load Amps
4.5-4.5/2.2
HP
1-1/2
Hz
60
Includes
Gasketed Conduit Box, Shaft Key, Shaft Slinger
Ins. Class
F
Item — Farm Duty Motors
General Purpose Farm Duty Motor
Length Less Shaft
11-1/2 in
Max Ambient Temperature
40 Degrees C
Motor Application
Farm Duty
Motor Bearings
Ball
Motor Design
3-Phase
Motor Enclosure Design
Totally Enclosed Fan-Cooled
Motor Frame Material
Rolled Steel
Motor Mounting Position
All Angle
Motor Mounting Type
Rigid Base
Motor Service Factor
1.15
Motor Shaft Design
Keyed
Motor Shaft Rotation
CW/CCW
Motor Sub Application
General Purpose Farm
Motor Thermal Protection
Manual
Nameplate RPM
1745
Nominal Efficiency
85.5 %
Overall Length
13-3/8 in
Phase
3
Shaft Diameter
5/8 in
Shaft Length
1-7/8 in
Standards
CSA Certified (258501), UL Recognized (E37403)
Voltage
208-230/460
Voltage Compatibility
208, 208-220/440, 208-230, 208-230/460, 208-240, 220-230/460, 220/460, 230, 230/460, 240, 460
