P/N: 40KH94 Key Specs
Item
AIR COMPRESSOR PUMP 1 STAGE 1 HP
OEM
Speedaire
OEM #
40KH94
Condition
New OEM Original
Returnable
No
Avg. Pump Life
5,000 hr
Bore Dia.
2 9/16 in
Construction
Cast Iron
Finish
Powder Coated
Flywheel Dia.
6 in
Flywheel Included
Yes
Free Air CFM @ Max. Pressure
1.3, 1.6, 1.9
Groove Quantity
1
Groove Section
A
HP
1/2 hp, 3/4 hp, 1 hp
Lubrication Type
Splash
Max. Pressure
115 psi
Mounting Pattern
3-1/8 in W x 4-5/8 in D
NPT Outlet
1/2 in
Number of Cylinders
1
Number of Stages
1
Oil Capacity
8 oz
Overall Depth
8 1/2 in
Overall Height
10 1/2 in
Overall Width
7 in
Pump RPM
820, 1,135, 1,425
Rotation
CCW
Sheave Size @ 1725 RPM
2 7/8 in, 3 61/64 in, 4 61/64 in
Sheave Size @ 3450 rpm
1 13/32 in, 2 13/32 in
Stroke Length
1 13/32 in
Valve Material
Stainless Steel
Valve Type
Reed
