P/N: 404TSTDCD6001 Key Specs
Item
MOTOR 3-PH 125 HP 3570 RPM 460V
OEM
Marathon Motors
OEM #
404TSTDCD6001
Condition
New OEM Original
Returnable
No
CC Number
CC003A
Duty
Continuous
Frame
404TS
Full Load Amps
138
HP
125
Hz
60/50
Includes
Conduit Box
Ins. Class
F
Inverter Rated
Yes
Length Less Shaft
29 5/8 in
Manufacturers Warranty Length
1 yr
Max Ambient Temperature
40 Degrees C
Motor Application
General Application
Motor Bearings
Ball
Motor Design
3-Phase
Motor Efficiency Group
NEMA Premium Efficient
Motor Enclosure Design
Open Dripproof
Motor Frame Material
Cast Iron
Motor Mounting Position
Horizontal
Motor Mounting Type
Rigid Base
Motor Service Factor
1.15
Motor Shaft Design
Keyed
Motor Shaft Rotation
CW/CCW
Motor Thermal Protection
None
Nameplate RPM
3570
Nominal Efficiency
80.4 %
Number of Speeds
1
Overall Length
33-7/8 in
Phase
3
Shaft Diameter
2-7/8 in
Shaft Length
4-1/4 in
Standards
UL (E49747), CSA (LR2025), CE
Voltage
460
