P/N: 3SDX15-SSVS-R3/6 Key Specs
Item
SPRING CHECK VALVE 316 SS 3 FLANGE
OEM
Champion Spark Plug
OEM #
3SDX15-SSVS-R3/6
Condition
New OEM Original
Returnable
No
Application — Valves
Process Piping
Body Material — Valves
316 Stainless Steel
Cap to Inlet Center
1-1/2 in
Connection Type — Check Valves
Flange x Flange
Cracking Pressure — Check Valves
0.198 psi
Flow Design
Single
Item — Check Valves
Check Valve
Length
5-3/8 in
Max Steam Pressure — Valves
Not Rated
Max Temperature — Valves
400 Degrees F
Max Water Pressure — Valves
275 psi @ 100 Degrees F
Mechanism and Body Design
Inline Spring
Mounting Orientation — Check Valves
Horizontal, Vertical
Overall Height
5-11/32 in
Pipe or Tube Size — Check Valves
3 in
Seal Material — Check Valves
Viton
Seat Material — Check Valves
Viton
Spring Material — Check Valves
316 Stainless Steel
Standards
API 594, API 598, ASME B16.34, ASTM A 351 Gr. CF8M ASME B16.5
Width
2 in
