P/N: 365TSTFCD6003 Key Specs
Item
MOTOR 3-PH TEFC 75 HP 3570 RPM 230/460V
OEM
Marathon Motors
OEM #
365TSTFCD6003
Condition
New OEM Original
Returnable
No
CC Number
CC003A
Duty
Continuous
Frame
365TSC
Full Load Amps
164/82
HP
75
Hz
60/50
Ins. Class
F
Inverter Rated
No
Length Less Shaft
32-1/2 in
Manufacturers Warranty Length
1 yr
Max Ambient Temperature
40 Degrees C
Motor Application
General Application
Motor Bearings
Ball
Motor Design
3-Phase
Motor Efficiency Group
NEMA Premium Efficient
Motor Enclosure Design
Totally Enclosed Fan-Cooled
Motor Frame Material
Cast Iron
Motor Mounting Position
Horizontal
Motor Mounting Type
Face/Base
Motor Service Factor
1.15
Motor Shaft Design
Keyed
Motor Shaft Rotation
CW/CCW
Motor Thermal Protection
None
Nameplate RPM
3570
Nominal Efficiency
76.2 %
Number of Speeds
1
Overall Length
36-1/4 in
Phase
3
Shaft Diameter
1-7/8 in
Shaft Length
3-3/4 in
Standards
UL (E49747), CSA (LR2025), CE
Voltage
230/460
