P/N: 354301 Key Specs
Item
JET IDP-22 22 INDUSTRIAL FLOOR MODEL DRILL PRESS 1-1/2HP, 115/230V, 1PH
OEM
Jet
OEM #
354301
Condition
New OEM Original
Returnable
No
Base Dimensions Inches
22-5/8 x 19-7/16 x 3-3/8
Base Slots Number & Size (In.)
2 and 5/8
Base Work Table (In.)
21-1/2 x 18-5/16
Chuck Size Inches
5/8
Column Diameter Inches
3-5/8
Distance Column To Spindle (In.)
10-7/8
Drilling Capacity Cast Iron
1-1/4
Drilling Capacity Mild Steel
1
Drills To Center Of Circle (In.)
22
Height Inches
67
Horsepower
1-1/2
Length Inches
35
Manaufacturer Warranty
2 Years
Model
IDP-22
Motor Horsepower
1-1/2 HP
Motor Phase
1 Ph
Motor Voltage
115/230V
Number Of Spindle Speeds
12
Prewired
115V
Range Of Spindle Speeds (Rpm)
175-3050
Spindle Distance To Base Inches
48-1/2
Spindle Distance To Table (Max/Inches)
28
Spindle Taper (In X Tpi)
MT-3
Spindle Travel Inches
4-13/16
Style
Floor
Style (Type)
Belt Drive
T-Slot Centers (In)
3/4
T-Slots Number And Size (In.)
2 and 5/8
Table Size (L X W)
18-5/8 x 16-1/8
Weight Lbs.
364
Width Inches
19
Work Table Weight Capacity (Lbs.)
176
