P/N: 351009AWL02L1000# Key Specs
Item
GAUGE PRESSURE 0 TO 1000 PSI 3-1/2 IN.
OEM
Ashcroft Inc.
OEM #
351009AWL02L1000#
Condition
New OEM Original
Returnable
No
Basic Gauge Case Material
Stainless Steel
Basic Gauge Lens Material
Plastic
Basic Gauge Sensor Material
Bronze
Basic Gauge Socket Material
Brass
Basic Gauge Wetted Parts
Brass / Bronze
Calibration Certificate Included
No
Gauge Accuracy
+/-1.50%
Gauge Application
General Purpose
Gauge Case Color
Stainless Steel
Gauge Case Material
304 Stainless Steel
Gauge Connection Location
Bottom
Gauge Connection Size
1/4 in
Gauge Connection Type
MNPT
Gauge Filled With
Glycerin
Gauge Lens Material
Polycarbonate
Gauge Nominal Dial Size
3-1/2 in
Gauge Panel Mountable
No
Gauge Primary Range Numbered Graduations
100
Gauge Primary Range Smallest Graduation
10
Gauge Primary Range Units
psi
Gauge Primary Range Values
0 To 1000
Gauge Sensor Material
Bronze
Gauge Socket Material
Brass
Gauge Special Options
PowerFlex(TM) Movement
Liquid Filled
Yes
Manufacturers Warranty Length
5 yr
Operating Temperature Range
-20 Degrees to 150 Degrees F
Pressure and Vacuum Gauge Type
Pressure Gauge
Series
1009AWL
