P/N: 324THFCD9026 Key Specs
Item
IEEE 841 MOTOR 3-PH TEFC 40 HP T2B
OEM
Marathon Motors
OEM #
324THFCD9026
Condition
New OEM Original
Returnable
No
CC Number
CC003A
Duty
Continuous
Frame
324T
Full Load Amps
47.5
HP
40 hp
Hz
60
Includes
Breather/Drain
Ins. Class
F
Length Less Shaft
23-3/8 in
Max Ambient Temperature
40 Degrees C
Motor Application
IEEE Motor
Motor Bearings
Ball
Motor Design
3-Phase
Motor Efficiency Group
NEMA Premium Efficient
Motor Enclosure Design
Totally Enclosed Fan-Cooled
Motor Frame Material
Cast Iron
Motor Mounting Type
Rigid Base
Motor Service Factor
1.15
Motor Shaft Design
Keyed
Motor Shaft Rotation
CW/CCW
Motor Thermal Protection
None
Nameplate RPM
1780
Nominal Efficiency
94.5 %
Number of Speeds
1
Overall Length
28-7/8 in
Phase
3
RPM Group
1701-1800
RPM Range
1701-1800
Shaft Diameter
2-1/8 in
Shaft Length
5-1/2 in
Standards
CE, CSA (LR2025), UL (E49747)
Voltage
230/460
