P/N: 31TT13 Key Specs
Item
MTR 3PH 1.5HP 1725 230/4600 EFF 86.5
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
31TT13
Condition
New OEM Original
Returnable
No
Duty
Continuous
Frame
56H
Full Load Amps
4.7/2.4
Green Certification or Other Recognition
Energy Aware Certified
Green Environmental Attribute
Product Contributes To Reducing Energy Consumption
HP
1 1/2 hp
Hz
60/50
Ins. Class
B
Inverter Rated
Yes
Length Less Shaft
11-1/2 in
Manufacturers Warranty Length
1 yr
Max Ambient Temperature
40 Degrees C
Motor Application
General Application
Motor Bearings
Ball
Motor Design
3-Phase
Motor Efficiency Group
Premium Efficient
Motor Enclosure Design
Open Dripproof
Motor Frame Material
Rolled Steel
Motor Mounting Position
All Angle
Motor Mounting Type
Rigid Base
Motor Service Factor
1.15
Motor Shaft Design
Keyed
Motor Shaft Rotation
CW/CCW
Motor Thermal Protection
None
Nameplate RPM
1725
Nominal Efficiency
86.5 %
Number of Speeds
1
Overall Length
13-7/16 in
Phase
3
RPM Group
1701-1800
RPM Range
1701-1800
Shaft Diameter
5/8 in
Shaft Length
1-7/8 in
Standards
UL Recognized for US and Canada (E47479)
Voltage
230/460
