P/N: 2812334 Key Specs
Item
WEDGE ANCHOR DIA.1/2 CS LN.3-3/4 PK10
OEM
MKT Fastening
OEM #
2812334
Condition
New OEM Original
Returnable
No
Agency Compliance
UL and FM
Anchor Diameter
1/2 in
Anchor Length
3-3/4 in
Anchor Material
Steel
Embedment In Concrete
2-1/4 in
Fastener Finish
Galvanized
Includes
Nut and Washer
Material Grade
Grade 2
Max Work Thickness
1-1/2 in
Meets/Exceeds
GSA SPEC FF-S-325C, GROUP II, TYPE 4, CLASS 1
Min Embedment
2-1/4 in
Seismic Approved
No
Thread Length
2-1/2 in
Thread Size
1/2-13
Ultimate Pullout (Pounds)
5,068
Ultimate Shear (Pounds)
6,828
Ultimate Shear in 3000 PSI Concrete (Pounds)
6,828
Ultimate Shear in 4000 PSI Concrete (Pounds)
6,828
Ultimate Tension (Pounds)
5,068
Ultimate Tension in 3000 PSI Concrete (Pounds)
4,120
Ultimate Tension in 4000 PSI Concrete (Pounds)
5,068
Wedge Anchor Type
Wedge Anchor
