P/N: 251009SW02LX6BVAC Key Specs
Item
D0992 VACUUM GAUGE 30 HG TO 0 2-1/2IN 1/4IN
OEM
Ashcroft Inc.
OEM #
251009SW02LX6BVAC
Condition
New OEM Original
Returnable
No
Basic Gauge Case Material
Stainless Steel
Basic Gauge Lens Material
Plastic
Basic Gauge Sensor Material
Stainless Steel
Basic Gauge Socket Material
Stainless Steel
Basic Gauge Wetted Parts
Stainless Steel
Calibration Certificate Included
No
Gauge Accuracy
+/-1.00%
Gauge Application
Oxygen Service Cleaned
Gauge Case Color
Stainless Steel
Gauge Case Material
304 Stainless Steel
Gauge Connection Location
Bottom
Gauge Connection Size
1/4 in
Gauge Connection Type
MNPT
Gauge Lens Material
Polycarbonate
Gauge Nominal Dial Size
2-1/2 in
Gauge Panel Mountable
No
Gauge Primary Range Smallest Graduation
0.5
Gauge Primary Range Units
in Hg
Gauge Primary Range Values
-30 to 0
Gauge Sensor Material
316 Stainless Steel
Gauge Socket Material
316 Stainless Steel
Gauge Special Options
PLUS!(TM) Performance
Liquid Filled
No
Manufacturers Warranty Length
5 yr
Operating Temperature Range
-40 Degrees to 150 Degrees F
Pressure and Vacuum Gauge Type
Vacuum Gauge
Series
1009
