P/N: 20RK80 Key Specs
Item
CONDENSER FAN MOTOR 1 HP 1140 RPM 60 HZ
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
20RK80
Condition
New OEM Original
Returnable
No
Application
Commercial Air Conditioners
Body Diameter
5/8 in
Duty
Continuous
Frame
56YZ
Full Load Amps
4.3-4.3/2.1
HP
1
Hz
60
Ins. Class
F
Lead Length
6 in
Length Less Shaft
9-3/4 in
Max Ambient Temperature
70 Degrees C
Motor Application
HVAC/R
Motor Bearings
Ball
Motor Design
3-Phase
Motor Enclosure Design
Open Air-Over
Motor Mounting Position
Vertical Shaft Up
Motor Mounting Type
Band
Motor Service Factor
1
Motor Shaft Design
Flat
Motor Shaft Rotation
CW/CCW
Motor Sub Application
Condenser Fan
Motor Thermal Protection
T-Stat
Nameplate RPM
1140
Nominal Efficiency
83.4%
Number of Speeds
1
Overall Length
15-3/4 in
Phase
3
Shaft Diameter
5/8 in
Shaft Length
5/8 in
Standards
CSA 191252, UL E47479
Voltage
208-230/460
