P/N: 2004007 Key Specs
Item
832 FEDERAL STYLE PROBE 120VAC OR BATTERY ELECTRONIC AMPLIFIER W RS-232 OUTPUT
OEM
Mahr
OEM #
2004007
Condition
New OEM Original
Returnable
No
Analog Minimum Grad#
.005/ .0005/ .00005/ 0.1mm/ .01mm/ .001mm
Auto Range
Automatically Selects The Smallest Ranre For Best Resolution
Calibration Accuracy
±1 digit
Color
Gray
Data Output
RS-232, Transmits Channels A, B, or Both, Units, and Tolerances
Digital I.O
Five TTL Opto-isolated Outputs
Digital Resolution
.0001 / .00001 / .000001 / .001mm/ .0001mm/ .00002mm
Gage Head Display
A, B Or Both At Any Time
Linear Error
Less Than .025 Percent Of Full Scale
Measuring Modes
Actual, Minimum, Maximum, T.I.R., Normal
Measuring Range
±0.100/ ±.010 / ± .001 / ±2mm / ±.200mm/ ±.020m
Power
US Battery/ 120VAC Charger
Repeatability
±1 digit
Response Time
43 msec.
Tolerance Indicators
Five LEDs
