P/N: 184TTDW16310 Key Specs
Item
CLOSE-COUPLED PUMP MOTOR 3490 RPM
OEM
Marathon Motors
OEM #
184TTDW16310
Condition
New OEM Original
Returnable
No
CC Number
CC003A
Duty
Continuous
Frame
184JMV
Full Load Amps
17.8/8.9
HP
7-1/2 in
Hz
60/50
Ins. Class
F
Inverter Rated
No
Length Less Shaft
13 in
Max Ambient Temperature
40 Degrees C
Motor Application
Pump
Motor Bearings
Ball
Motor Design
3-Phase
Motor Efficiency Group
NEMA Premium Efficient
Motor Enclosure Design
Open Dripproof
Motor Frame Material
Rolled Steel
Motor Mounting Type
Face
Motor Service Factor
1.15
Motor Shaft Design
Keyed and Drilled On Center
Motor Shaft Rotation
CW/CCW
Motor Sub Application
Close-Coupled Pump
Motor Thermal Protection
None
Nameplate RPM
3490
Nominal Efficiency
88.5 %
Overall Length
17-1/8 in
Phase
3
Shaft Diameter
7/8 in
Shaft Length
4-1/8 in
Standards
CSA Certified (LR2025), UL Recognized (E49747)
Voltage
230/460
Voltage Compatibility
220-230/460, 230/460, 460
