P/N: 1520-20 Key Specs
Item
SWING CHECK VALVE PVC 2 SOCKET
OEM
Nds
OEM #
1520-20
Condition
New OEM Original
Returnable
No
Application — Valves
General Purpose
Body Material — Valves
PVC
Connection Type — Check Valves
Socket x Socket
Cracking Pressure — Check Valves
0.25 psi
Flow — Valves
78.44 gpm
Flow Design
Single
Full Flow — Valves
Yes
Item — Check Valves
Check Valve
Length
6-3/16 in
Max Steam Pressure — Valves
Not Rated
Max Temperature — Valves
140 Degrees F
Max Water Pressure — Valves
150 psi @ 70 Degrees F
Mechanism and Body Design
Inline Swing
Min Temperature — Valves
14 Degrees F
Mounting Orientation — Check Valves
Horizontal, Vertical
Overall Height
4-19/64 in
Pipe or Tube Size — Check Valves
2 in
Seal Material — Check Valves
EPDM
Seat Material — Check Valves
PVC
Standards
NSF 61
Width
4-19/64 in
