P/N: 12SDX15-SSVS-R2/5 Key Specs
Item
WAFER CHECK VALVE 316 SS 12 FLANGE
OEM
Champion Spark Plug
OEM #
12SDX15-SSVS-R2/5
Condition
New OEM Original
Returnable
No
Application — Valves
Process Piping
Body Material — Valves
316 Stainless Steel
Cap to Inlet Center
1-1/2 in
Connection Type — Check Valves
Flange x Flange
Cracking Pressure — Check Valves
0.241 psi
Flow Design
Single
Item — Check Valves
Check Valve
Length
16-1/8 in
Max Steam Pressure — Valves
Not Rated
Max Temperature — Valves
400 Degrees F
Max Water Pressure — Valves
275 psi @ 100 Degrees F
Mechanism and Body Design
Inline Wafer
Mounting Orientation — Check Valves
Horizontal, Vertical
Overall Height
13-21/32 in
Pipe or Tube Size — Check Valves
12 in
Seal Material — Check Valves
Viton
Seat Material — Check Valves
Viton
Spring Material — Check Valves
316 Stainless Steel
Standards
API 594, API 598, ASME B16.34, ASTM A 351 Gr. CF8M ASME B16.5
Width
3-1/2 in
