P/N: 1201010 Key Specs
Item
SWING CHECK VALVE PVC 1 FLANGE
OEM
Asahi
OEM #
1201010
Condition
New OEM Original
Returnable
No
Application — Valves
General Purpose
Body Material — Valves
PVC
Connection Type — Check Valves
Flange x Flange
Cracking Pressure — Check Valves
1 psi
Flow Design
Single
Full Flow — Valves
Yes
Item — Check Valves
Check Valve
Length
6-19/64 in
Max Steam Pressure — Valves
Not Rated
Max Temperature — Valves
120 Degrees F
Max Water Pressure — Valves
150 psi @ 120 Degrees F
Mechanism and Body Design
Inline Swing
Min Temperature — Valves
30 Degrees F
Mounting Orientation — Check Valves
Horizontal, Vertical
Overall Height
4-39/64 in
Pipe or Tube Size — Check Valves
1 in
Seal Material — Check Valves
EPDM
Seat Material — Check Valves
EPDM
Standards
ASTM D1784 Cell Class 12454A
