P/N: 10SDX12-LTBS-P2/5 Key Specs
Item
WAFER CHECK VALVE IRON 10 FLANGE
OEM
Champion Spark Plug
OEM #
10SDX12-LTBS-P2/5
Condition
New OEM Original
Returnable
No
Application — Valves
Process Piping
Body Material — Valves
Ductile Iron
Cap to Inlet Center
1-1/2 in
Connection Type — Check Valves
Flange x Flange
Cracking Pressure — Check Valves
0.23 psi
Flow Design
Single
Item — Check Valves
Check Valve
Length
13-3/8 in
Max Steam Pressure — Valves
Not Rated
Max Temperature — Valves
250 Degrees F
Max Water Pressure — Valves
250 psi @ 100 Degrees F
Mechanism and Body Design
Inline Wafer
Mounting Orientation — Check Valves
Horizontal, Vertical
Overall Height
14-5/32 in
Pipe or Tube Size — Check Valves
10 in
Seal Material — Check Valves
Buna-N
Seat Material — Check Valves
Buna-N
Spring Material — Check Valves
316 Stainless Steel
Standards
API 594, API 598, ASME B16.42, ASME B16.5, ASTM A 351 Gr. CF8M, ASTM A 395 Gr. 60-40-18
Width
3-1/8 in
