P/N: 056T34F15592 Key Specs
Item
MOTOR 2 HP 3 450 RPM 56J 230/460V
OEM
Marathon Motors
OEM #
056T34F15592
Condition
New OEM Original
Returnable
No
Body Diameter
6-1/2 in
CC Number
CC003A
Duty
Continuous
Frame
56J
Full Load Amps
5/2.5
Green Certification or Other Recognition
NEMA Premium(R) Rated
HP
2
Hz
60/50
Ins. Class
B
Max Ambient Temperature
40 Degrees C
Motor Application
Pump
Motor Bearings
Ball
Motor Design
3-Phase
Motor Efficiency Group
NEMA Premium Efficient
Motor Enclosure Design
Totally Enclosed Fan-Cooled
Motor Mounting Position
Horizontal
Motor Mounting Type
Face/Base
Motor Service Factor
1.15
Motor Shaft Design
Threaded
Motor Shaft Rotation
CW/CCW
Motor Sub Application
Jet Pump
Motor Thermal Protection
None
Nameplate RPM
3450
Nominal Efficiency
86.5 %
Overall Length
14-13/16 in
Phase
3
Shaft Diameter
5/8 in
Shaft Length
2-3/8 in
Shaft Material
416 Stainless Steel
Standards
CE Approved, CSA (LR2025), UL (E49747)
Voltage
230/460
Voltage Compatibility
208, 208-220/440, 208-230, 208-230/460, 208-240, 220-230/460, 220/460, 230, 230/460, 240, 460
