P/N: 0.75DPSRM06.00 Key Specs
Item
ROUND AIR CYLIN 3/4INBORE 6INSTROKE
OEM
Parker Hannifin Corporation
OEM #
0.75DPSRM06.00
Condition
New OEM Original
Returnable
No
Air Cylinder Bore Dia.
3/4 in
Air Cylinder Mount
Nose and Pivot
Air Cylinder Product Group
Air Cylinder
Air Cylinder Type
Round Body
Body Material
Stainless Steel
Bore Dia.
3/4 in
Cushion Type
None
Cylinder Action
Double Acting
Cylinder Type
Round Non-Repairable
End Cap Material
Aluminum
Finish
Silver
Magnetic Piston
Yes
Max. Pressure
250 psi
Mount
Nose and Pivot
Nose Mount Thread
5/8-18
Overall Length
10.53 in
Piston Material
Aluminum
Piston Rod Material
Stainless Steel
Pivot Hole Dia.
0.251 in
Port Size
1/8 in FNPT
Rod Dia.
0.25 in
Rod Thread Length
0.5 in
Rod Thread Size
1/4-28 UNF
Single Acting/Double Acting
Double Acting
Stroke
6 in
Temp. Range
14 Degrees to 140 Degrees F
Tube Material
Stainless Steel
