P/N: 0.56NSR03.00 Key Specs
Item
ROUND AIR CYLIN 9/16INBORE 3INSTROKE
OEM
Parker Hannifin Corporation
OEM #
0.56NSR03.00
Condition
New OEM Original
Returnable
No
Air Cylinder Bore Dia.
9/16 in
Air Cylinder Mount
Nose
Air Cylinder Product Group
Air Cylinder
Air Cylinder Type
Round Body
Body Material
Stainless Steel
Bore Dia.
9/16 in
Cushion Type
None
Cylinder Action
Single Acting
Cylinder Type
Round Non-Repairable
End Cap Material
Aluminum
Finish
Silver
Magnetic Piston
No
Max. Pressure
250 psi
Mount
Nose
Nose Mount Thread
7/16-20
Overall Length
6.9 in
Piston Material
Aluminum
Piston Rod Material
Stainless Steel
Port Size
#10-32 UNF
Rod Dia.
0.188 in
Rod Thread Length
0.5 in
Rod Thread Size
#10-32 UNF
Single Acting/Double Acting
Single Acting
Spring Retraction Force
2 lb
Stroke
3 in
Temp. Range
-10 Degrees to 165 Degrees F
Tube Material
Stainless Steel
