Data Sheet: NM30LA Data Sheet.pdf
Refurbished Peak NM30LA nitrogen generator. The NM30LA Nitrogen Generator is Peak Scientific Instruments» proven solution for customers requiring Nitrogen for their LC/MS Application. Specifically designed to supply LC/MS/MS analysers, the NM30LA produces nitrogen gas at the required flow rates, purities and pressures for these instruments. The produced nitrogen gas is filtered down to 0.01 micron and passed through an Active Carbon Filter to minimize the risk of contamination.
Quiet in operation the NM30LA utilises separation technology to selectively remove oxygen, moisture and other gases to leave clean, dry, phthalate free nitrogen. 2 Internal Air Compressors make the NM30LA a stand-alone, self- sufficient Nitrogen Generator, independent from external air sources.
NM30LA Technical Specification Max Flow Rate: 30L/min ATP Max Outlet Pressure: 100psi / 6.89bar Nitrogen Pressure Dewpoint: -40C / -40F Internal Air Compressor: Yes Noise Level: 59db(A) Electrical Requirements: 230v 50/60Hz 5.0A Power Consumption: 1,150 watts Dimensions WxDxH: 60x67x94cm / 24x27x37ins Weight: 112.5kg / 248lbs
Please contact us for complete Peak Scientific nitrogen generator warranty details.
