Laser marker VIS-P – Class 1 Thanks to its compactness, Vis perfectly adapts to handheld version. Available standard laser sources: • IVO4 to mark metals and alloys, plastics and anodized, painted surfaces • Air cooled • Standard marking area 110×110 mm (available other marking areas) Software Genius easy to learn, multilingual, many laser parameters to meet all marking requests: • Serial numbers, texts – arc text – with full TTF compatibility, • Basic geometrical figures , shift and data codes in different formats, • Barcodes and 2D/Datamatrix • Dxf – wmf – plt – emf and Raster import • Connection via Ethernet • PC connected or Stand Alone version all in one” – robust, compact and versatile laser unit, with a perfect integration of • Galvanometric head • Laser source • Electronics • External power supply Handheld structure with two handles and a front standoff, to grant equilibrium and stability during marking Telescope for an easy and perfect laser beam focus Security Class: 1 Dimension: 360 x 173 x 167 mm Materials: Silicon Plastics Painted Metal Ceramics
Технические характеристики
CharacteristicsTechniqueNd:YVO4 laserMaterialmetal, plastic, ceramic, for siliconConfigurationfor integration, hand-heldOther characteristicscompact, air-cooledPower
Max.: 40 W (0.05 hp)
Min.: 3 W (0 hp)
X travel
110 mm (4 in)
Y travel
110 mm (4 in)
