Features:
- Cable length 1.2 m
- Bandwidth DC to 150 MHz
- Risetime 2.33 ns
- Attenuation ratio 10:1
- Input resistance 10 MΩ (when terminated into 1 MΩ)
- input capacitance ≈12 pF
- Maximum input 300 V RMS
- Compatible with the 1000 and 3000 Series and DSO5012A/DSO5014A oscilloscopes
The Agilent Keysight N2862A low-cost passive probe provides a 10:1 attenuation and features a high input resistance of 10 MΩ. The probe can be adjusted for low-frequency compensation and high-frequency compensation.
For the best measurements you should compensate your probe to match its characteristics to the oscilloscope.
Технические характеристики
| Manufacturer | Agilent, HP, Keysight |
|---|---|
| Condition | Used |
| Voltage | 300 V |
| Frequency | 150 MHz |
