Description
Features:
Liquid sample storage,Wide neck opening,Lowest liftover height,Largest LN2 capacity
Specifications:
Maximum Storage Capacity
- 1.2 & 2 ml Vials (Internally Threaded): 5,200
- Quantity of Large Racks 100 cell boxes: 4
- Quantity of Mini Racks 25 cell boxes: N/A
- Number of Shelves per Rack: 13
- High Security Straw Capacity (0.5 ml): 19,320
- Number of Canisters (73 mm): 23
- Goblets/Canister : Straws/Goblet: 5:168
Performance
- • LN2 Capacity w/o Inventory : 95 L
Unit Dimensions
- Neck Opening: 16.0″ (406 mm)
- Useable Internal Height: 28.9″ (735 mm)
- Inner Diameter: 16.0″ (406 mm)
- Overall Height: 46.3″ (1176 mm)
- Door Width Requirement: 23.6″ x 22.7″ (601 x 577 mm)
- Weight Empty: 195 lb. (88 kg)
- Weight Full* (liquid) est.: 365 lb. (166 kg)
Blood Bag Capacities
- 791 OS/U Medsep (25 ml) – total bags: 539
- 4R9951 (50 ml) – total bags: 228 – Bags/Frame: 6 – No. Frames: 38
- 4R9953 (250 ml) – total bags: 128 – Bags/Frame: 4 – No. Frames: 32
- 4R9955 (500 ml) – total bags: 96 – Bags/Frame: 4 – No. Frames: 24
- DF200 (200 ml) – total bags: 80 – Bags/Frame: 4 – No. Frames: 20
- DF700 (700 ml) – total bags: 40 – Bags/Frame: 4 – No. Frames: 10
