CONEX-LTA-HL is a high load motorized actuator integrated with a CONEX-CC controller and is recommended for heavy load applications with 25 mm travel. LTA actuators are designed to fit into existing manual stages, and other opto-mechanical components as direct replacement for manual micrometers. Features include a non-rotating tip to eliminate wear, and folded motors to minimize the footprint and unwanted cantilevered loads.
The CONEX™ controller comes with a USB cable and a CONEX-PS-CB for daisy-chaining modules. Power supply to be ordered separately. For OEM applications, an optional retainer to secure the USB and power cables is available.
Технические характеристики
- Stage Type LTA-HL Linear Actuator
- Travel Range 25 mm
- Push Force 120 N
- Pull Force 100 N
- Maximum Speed 1 mm/s
- Minimum Incremental Motion 0.05 m
- Absolute Accuracy, Typical ±,1.2 m
- Absolute Accuracy, Guaranteed ±,3.0 m
- Uni-directional Repeatability, Typical ±,0.10 m
- Uni-directional Repeatability, Guaranteed ±,0.25 m
- Bi-directional Repeatability, Typical ±,0.30 m
- Bi-directional Repeatability, Guaranteed ±,1.0 m
- Drive Type DC servo
- Origin Repeatability ±,2 m
- Encoder Resolution 0.00737358 m
- Control Loop Floating point digital PID loop with velocity and friction feedforward, 2 kHz servo rate
- Display Two-color LED
- Programming 40+ intuitive, 2 letter ASCII commands.
- Power Requirements 24 VDC, 8 W
- Cable Length 3 m
- Computer Interfaces USB
- Controller Dimensions 93.2 x 53 x 23 mm
- MTBF 10,000 h (25% load, 30% Duty cycle)
- Compliance RoHS 3, CE
