The M-IMS400BPP Linear Stage with Stepper Motor uses the same industry-proven technology as the ILS Series. The stage features a robust design and high performance at low cost, making it a cost-effective solution for precision industrial and laboratory applications. Features include: recirculating ball bearing slides to provide excellent payload capabilities and long life, FEM-optimized extruded aluminum body to avoid bending effects or deflection under load. The preloaded, backlash-free ballscrew version provides rapid motion with fast, step and settling times Position is read with a 4000 pts/rev. encoder mounted directly on the screw. This stage is ideal for many precision industrial applications such as semiconductor wafer inspection, micro-electronics test and assembly, pick and place, DNA sequencing or laser machining.
Технические характеристики
- Travel Range 400 mm
- Maximum Speed 100 mm/s
- Minimum Incremental Motion 1250 nm
- Centered Load Capacity 600 N
- Axial Load Capacity (+Cx) 30 N
- Inverse Axial Load Capacity (-Cx) -30 N
- Accuracy, Typical ±,2.5 m
- Accuracy, Guaranteed ±,5.0 m
- Uni-directional Repeatability, Typical ±,0.50 m
- Uni-directional Repeatability, Guaranteed ±,0.65 m
- Bi-directional Repeatability, Typical ±,0.75 m
- Bi-directional Repeatability, Guaranteed ±,1.25 m
- Pitch, Typical ±,37 rad
- Pitch, Guaranteed ±,75 rad
- Compliance in Pitch 0.2 rad/Nm
- Yaw, Typical ±,15 rad
- Yaw, Guaranteed ±,75 rad
- Compliance in Yaw 1 rad/Nm
- Compliance in Roll 1 rad/Nm
- Drive Type Stepper Motor
- Feedback Rotary Encoder
- Origin Repeatability ±,0.5 m
- Cable Length 5 m
- Thread Type M6
- Weight 18.7 kg
- MTBF 20,000 h (25% load, 30% duty cycle)
- Compliance RoHS 3, CE
