last updated : 2018/12/31
| Code | Description | Budget Price | Ship. weight | Ship. vol. | ||
|---|---|---|---|---|---|---|
| KWATPUMCRW03 | KIT, MOTOR PUMP, raw water, diesel, 3′, 48m3/h at 25m | CH 4 450,58 | 207kg | 0,88m³ | Add | |
| Dangerous : DGR-UN3528 | ||||||
General information
Self-priming diesel pump 3 inch / 6.7kW with LOMBARDINI 3L D510 engine.
- Specify the type of engine in your order if other than the Lombardini.
- Alternative types may differ in characteristics from the standard type.
This pump accepts raw water with limited amounts of very small solids.
Spare parts set suitable for starting operation.
Specifications
Standard engine: | Lombardini 3L D510 (Diesel)/6.7kW at 3000rpm |
Alternative engines: | Lister LV1(Diesel)/6.7kW at 3000rpm Hatz 1D50-1(Diesel)/6.6kWat 3600rpm |
Engine specifications: | 4-stroke diesel, single cylinder, direct injection, not turbo charged, air-cooled, variable speed control, recoil manual star, dry air filter. exhaust silencer, oil and fuel filters, low oil-level security cut-off, 4 litre-minimum fuel tank |
Pump: | centrifugal self-priming pump in cast iron construction, integral non-return valve, replaceable rubber-coated wear plate, cast-iron high efficiency clog-resistant impeller, 19mm-max solids handling, carbon/ceramic faced mechanical seal, detachable discharge bend and screwed BSP suction/discharge connections |
Other features: | Engine close coupled with pump. Mounted on prefabricated steel base with 2-wheeled site trolley. |
Packaging: | One side of the packaging box is designed as a detachable ramp for loading and offloading the pump. Inside the box, a divider protects the components. Inside of box lined with a tar-coated paper for water protection. |
KWATPUMCRW03 Content list — Export content list (excel file)
| Code | Description | Qty |
|---|---|---|
| APACWBOX1108 | BOX, 20mm plywood, 1.1×0.7×0.8m, pallet base + ramp | 1 |
| EHDWBACLH077 | BAND CLIP, for hose pipe, high torque, 77-95mm | 2 |
| TVEAFUNNP200 | FUNNEL, diam. 200 mm, bended + metallic filter | 1 |
| TVEAJCANM20L | JERRYCAN, 20 l, metallic certified UN | 1 |
| TVECLUBR501 | OIL, ENGINE, diesel/petrol, 15W40, 5L plastic container | 1 |
| WNEASTNR3 | STRAINER+check valve, 3′, thread fem. | 1 |
| WNECBRCA3M3T | COUPLING, BRASS, ADAPTOR, thread. male 3′ to hosetail 3′ | 1 |
| WNECGABB3F3F | COUPLING, GALVA, BEND, 3′, 90deg ,thr fem/fem,large radius | 1 |
| WNECGANN3M3M | COUPLING, GALVA, NIPPLE, 3′, threaded male/male | 2 |
| WNECSTCC3SM | COUPLING, ‘Storz’, 3′, threaded male | 2 |
| WNECSTHO2-3 | HOOK SPANNER, for 2′ and 3′ Storz couplings | 1 |
| WNEVBRGA3FF | VALVE, BRASS, GATE, 3′, threaded fem/fem | 1 |
| WPUCESDR002 | PUMP, END-SUCTION, diesel, Self-Priming, 3’/6.1kW | 1 |
| WSPPLOMB3647 | FUEL FILTER, element, Lombardini 15LD/3LD, ref SK3647 | 1 |
| WSPPLOMB4701 | OIL FILTER, Lombardini 3LD510, ref FT4701 | 1 |
| WSPPLOMB6103 | VALVE, rubber, Paio pump, ref:6103 | 1 |
| WSPPLOMB6339 | MECHANICAL SEAL, Quiete/Paio pumps, ref:6339+6353 | 1 |
| WSPPLOMBGUPA | USER + SPARE PART GUIDE, Lombardini Paio | 1 |
