A.H. Systems Active Monopole Antenna is an active, general-purpose, broadband monopole antenna. Features 9 KHz to 60 MHz Individually Calibrated FCC, MIL-STD, VDE and TEMPEST Testing Rugged Construction Three Year Warranty Product Details Looking for the perfect for low frequency omni-directional antenna. The SAS-550-1B active monopole antenna is ideal for instantaneous bandwidth scanning (without tuning) of electric fields from 9 KHz — 60 MHz. It’s well suited for test technicians performing FCC, MIL-STD and TEMPEST low frequency tests. A fully charged hefty 2000 mAH battery will last a full work day for continuous testing, and this 104cm rod antenna has a signal output connector that is electrically bonded to the matching network case per MIL-STD 461F. This model boasts A.H. Systems’ amazing 3 year warranty too, so you’ve got complete peace of mind. The SAS-550-1B comes with a telescoping rod, ground plane, high impedance matched preamplifier and battery charger. Included parts: SAS-550-1B Antenna Base with ground plane Telescoping Antenna Element Battery Charger Antenna Calibration Manual * Calibration data and certificate included.
Технические характеристики
CharacteristicsNetworkradio, broadbandTypeomnidirectional, rod, monopoleOther characteristicsrugged, activeApplicationsmeasurement, for EMI/EMC testingFrequency
Max.: 60,000 kHz
Min.: 9 kHz
