Description
Includes:
- Computer Loaded w/ Softmax Pro 5.4.1
- StakMax Microplate Handling System for automated multi-plate assays
High sensitivity glow and flash luminescence detection from an upgradeable platform, offering up to six times the throughput of conventional microplate readers.
General Specifications
- Dimensions (in.): 16.5 (W) x 17 (D) x 8.75 (H)
- Dimensions (cm): 42 (W) x 43 (D) x 22 (H)
- Weight: 36 lbs. (16.4 kg)
- Power source: 230 Vac 50 Hz, 115 Vac 60 Hz
- Detector: Low-noise photomultiplier tube with simultaneous photon counting and analog mode
- Plate formats: Standard 96- and 384-well microplates, with heights from 13.5-15.5 mm
Performance Specifications
- Cross-talk (96-well): 3 x 10-5
- Read modes: Endpoint, Kinetic, Fast Kinetic, Dual-Read
- Injector: 2 variable volume injectors (10-200 l) per read head
- Injector accuracy: ±,1 L ±,2%
- Injector precision: ±,1 L ±,2%
- Sensitivity (96-well): <, 20 attomol ATP per well, <, 0.2 fg firefly luciferase per well
- Spectral range: 380-630 nm
- Dynamic range: 9 orders of magnitude
