Технические характеристики
| Type | Compact type |
|---|---|
| Input Voltage | +4.75 V to +5.25 V |
| Max. Input Current | 125 mA |
| Specification Guaranteed Output Voltage Range | +10 V to +250 V |
| Output Voltage Accuracy | +/-0.5 % |
| Max. Output Voltage | +250 V |
| Max. Output Current | 1 mA |
| Response Time | 40 ms |
| Line Regulation | +/-0.01 % |
| Load Regulation | +/-0.01 % |
| Temperature Coefficient (Typ.) | +/-0.01 %/℃ |
| Ripple/Noise (Typ.) | 10 mV |
| Output Controlling Voltage | 0 V to +2.5 V |
| Operating Ambient Temperature | -10 ℃ to +60 ℃ |
| Operating Ambient Humidity | Below 85 % |
| Storage Temperature | -20 ℃ to +70℃ |
| Storage Humidity | Below 85 % |
| Dimensions (W x H x D) | 26 x 8 x 17 mm |
| Weight | 6 g |
