The F-MBE (Mfg. P/N: CF01493-15) Bend-insensitive, pure silica, step index, multimode Sensor Grade Fiber features a core diameter of 1000 &mu,m. A hard clad silica 1035 &mu,m cladding enhances the fibers strength and fatigue resistance. A high NA of 0.37 allows greater coupling efficiencies, while making these fibers optimal for applications requiring tight bending or coiling of fibers.
Its typical 500-1100 nm applications include medical, industrial and avionic sensors and instruments. The operating temperature of the F-MBE is -65C to +125C.
Standard pricing is per meter.
Технические характеристики
- Index Profile Step
- Fiber Type Multimode
- Core Diameter 1000 ±15 m
- Cladding Diameter 1035 ±15 m
- Coating Diameter 1400 ±50 m
- Operating Wavelength 500-1100 nm
- Buffer Coating Material Dual Acrylate
- Bend Radius 60 min./20 yrs. 73/118 mm
- Numerical Aperture 0.37
- Proof Test 100 kpsi
