The HVC 140 platform offers a broad range of metal-working solutions, not just outstanding spindles. The platform concept serves mold makers and inner grinding applications. The HVC 140 spindle platform accommodates housing diameters as small as 140mm, with speeds from 10,000 to 42,000 rpm, moderate power from 3 to 10 kW S1 and torque from 3 to 16 Nm S1. The Opticool system and COOL-Core technology provide polar temperature stability for repeatable, reliable machining processes. For multiple-process machining, including grinding and milling, P2-quality bearings back the stiff bearing assignment to yield minimal runout. The Spindle Exchange Program (SEP) guarantees no more than 24 hours of downtime (EU) to maximize machine availability and minimize capital investment in spindles.
Технические характеристики
CharacteristicsFunctionfor milling, drilling, grindingOther characteristicshigh-speed, with automatic tool changer, high-frequencyRotational speed
Min.: 10,000 rpm (62,831.85 rad.min-1)
Max.: 42,000 rpm (263,893.78 rad.min-1)
Diameter
140 mm (5.5 in)
