Description
Specifications:
- Tem. Range: +50C to -350C
- Automatic defrosting: 1 each 24h
- Section thickness range: 1 – 500 µm
- Fine section thickness range: 1 – 20 µm
- Resolution: 1 µm for 1 – 10 µm , 2 µm for 10 – 20 µm
- Trimming thickness range: 10 – 500 µm
- Resolution: 10 µm for 10 – 80 µm, 20 µm for 80 – 100 µm, 50 µm for 100 – 300 µm, 100 µm for 300 – 500 µm
- Specimen retraction during return travel: 40 µm
- Horizontal feed range: 28 mm
- Vertical specimen stroke: 64 mm
- Section counter: 5 digit LED display with reset
- Sum of section thicknesses: 5 digit LED display with reset
- Remaining travel to front end position: 5 digit LED display
- Size of specimen stages: 30, 40, 50, 55, 60, 70 mm, special sizes upon request
- Specimen orientation: x- and y- axes: universal 80 , z- axis: up to 3600
- Cutting drive: manual by means of handwheel
- Coarse feed: motorized, graduated and continuos
- Storage temperature range: -200C to +500C
- Operating conditions: +50C to +400C(at a max. Rel. humidity of 60%), altitude up to 2000 m M.S.L, for indoor use only
- Power requirements: 100V/12A – 240V/8A
- Pollution degree: 2
- Overvoltage category: II
- Dimensions(WxDxH): 775x800x1200 mm
- Weight: 135 kg
