Operation Mode: — USB 3.0 Input/Output Interface: — USB Type B Transmission Line Interface: — LC optical connector is standard Transmission Distance: — See distance chart System Wavelength: — 850 or 1300 nm Bit Error Rate: — 10-9 Operating Temperature: — 0 °C to 40 °C Weight: — 0.75 lb (340 grams) Input Power: — 5VDC External with power supply — 5W typical (S.I.Tech #2166 — 100 to 240 VAC, 50/60 Hz, to 5VDC, UL, CE, & TUVGS Listed) Locking Connecter Metal Enclosure: — 3.9′ x 3.0′ x 1.00′ Features: Supports USB 3.0 over fiber Smaller and Compact size than 2172 Support all major operating systems — Windows, Mac, OSX, Linux Power, Link Status, and Host LED indicators LC optical connectors Plug and Play Extend USB 3.0 on multimode fiber up to 100m Not backward compatible with USB1.1 and 2.0 S.I.Tech 2187/2188 USB media converter pair extends the range of USB 3.0 beyond the USB 5 meter limit. The USB media converters are compliant with the USB 3.0 specification supporting full speed of 5Gbs USB data transfer.
Технические характеристики
CharacteristicsTypemediaBusfiber opticOther characteristicsUSB
